Silverthin SP1629-14 Mating Pinion for SK6 Series Slewing Rings

Request Quote

Overall Dimensions

Length of Pinion (L1) 2.880 in
Pitch Diameter (D1) 3.500 in
Outside Diameter (Do1) 3.900 in
Hub Diameter (Dr1) 2.880 in
Stock Bore (Di1) 1.000 in
Square Key Size, nominal (w) 1/4 in
Approximate Weight 6.40 lbs

Gear Data (α = 20°)

Tooth Form Stub involute spur gear
Number of Teeth (z1) 14
Diametral Pitch (Pd) 4
Face Width (b1) 2.00 in

Compatible Bearings

Part Numbers SK6-16 thru SK6-29
